$100.00
Out diameter 3.9mm 3.8mm 720P endocspe camera module is used for CMOS OV9734 1/9″ sensor. Separately from the PCBA : PCB decoder + Camera moudule. Application for Industrial endoscopic, for Medical endoscope. Like: Endoscopy of digestive tract; Hysteroscopy; Anorectal endoscopy; Urinary endoscopy; Disposable endoscopy , GI and so on.
10000 in stock (can be backordered)
This endoscopy camera module is used for CMOS OV9734 1/9″ sensor, with resolution 1280*720P, high frame rate 30FPS. It can not only be made into an outer diameter of 3.3MM Endoscope camera module, 3.5MM endoscopic camera module , but also can be made into an outer diameter of 3.8MM 3.9MM endoscope camera module.
3.9mm 720P endoscope camera module with LED and with Stainless Steel Sleeve, LED CCT is 5500K-6500K, 4PCS LED . Camera module Length is 13±0.1mm.
The standard FOV(Diagonal) of 3.9mm endoscopic camera module is Diagonal 100 degree. Its depth of field is 10-50mm.
Diameter of cable is 0.95mm. The length of cable is from 50mm -2 meters, but only out diamter 1.85mm can be 5 Meters. The max length of USB output is 2 meters.
Progressive Scan Mode.
The endoscopic camera module can be supported output for AV;USB. Separately from the PCBA : PCB decoder + Camera moudule.
Application for Industrial endoscopic; Endoscopy of digestive tract; Hysteroscopy; Anorectal endoscopy; Urinary endoscopy; Disposable endoscopy , Dental endoscope camera and so on.
| Item NO. | CBT-720P-E3.9 |
| Sensor | OV9734 1/9”CMOS |
| Out Diameter | φ3.9mm With Stainless Steel Sleeve) |
| Camera module Length | 13±0.1mm |
| Resolution | 1280X720P@30FPS |
| LENS Diameter | 2.0mm |
| FOV（Diagonal） | 100°/120° |
| Depth of field | 10-50mm/8-50MM |
| Back end cable diameter | φ0.95mm |
| Back end cable length | 2500mm |
| LED QTY | 4PCS LED |
| / | / |
| Scan model | Progressive |
| Operating Temperature | -0 ℃ – +45℃ |
| Separately from the PCBA | Camera Module + PCB |
| Supporting image processing board | USB |
| Weight | 0.5 kg |
|---|---|
| Dimensions | 18 × 15 × 12 cm |
| Out Diameter | 3.9MM |
| Sensor | OV9734 |
| Resolution | 1280X720P |
| FOVD | 100°, 120°, 140° |
| Depth of filed | 10-50MM, 3-100MM, 5-50MM, 8-50MM |
| Camera Head Length | 10MM, 13MM, 15MM, 170MM, 250MM, 7MM |
| Front End Cable Length | 1 Meter, 2 Meters, 3 Meters |
| USB Cable Length | 1 Meter |
| Output | USB |
